Three piece flange ball valve
Ball valve(flanged,wafer)
The three piece flange ball valve of Anix is manufactured on the basis of many years’ experience in development and manufacture of ball valves:
1. the valve seat is designed to be of double lip seal structure to enhance sealing and reduce the operation torque; the valve seat can be made of various materials, suitable for more areas;
2. the valve rod is designed to be of explosion proof structure and bottom mounting type to prevent flying out under pressure; PTFE guide is also used to reduce friction on the valve rod and reduce the operation torque;
3. the valve is designed to be of fireproof and anti-static structure; the fireproof and anti-static structure can also be customized according to the requirements of the customers or the working conditions; 4. the valve is designed to be of three piece structure to be easy for maintenance.
Need to see more product information or to request high-quality print copy please contact us
Contact us|
Design standards |
|
Technical code: American standard Design standard: API6D API608 Structural length: ASME B16.10 Connecting flange: ASME B16.5 Test and inspection: API6D API598 |
|
Performance Specification |
|
Nominal pressure: 150, 300, 600LB Strength test: 3.0, 7.5, 15Mpa Seal test: 2.2, 5.5, 11Mpa Back seal test: 2.2, 5.5, 11Mpa Gas seal test: 0.6Mpa Valve body material: WCB(C), CF8(P), CF3(PL), CF8M(R), CF3M(RL) Applicable media: water, oil, gas, chemical industry, power stations, etc. Applicable temperature: -29℃ to 180℃ |
|
Product Structure |
 |
