fully-welded ball valve

Ball valve(flanged,wafer)

Fully-welded ball valve is divided into butt weld (BW) and socket weld (SW) types 。
1. the valve seat is designed to be of double lip seal structure to enhance sealing and reduce the operation torque; the valve seat can be made of various materials, suitable for more areas;
2. the valve rod is designed to be of explosion proof structure and bottom mounting type to prevent flying out under pressure; PTFE guide is also used to reduce friction on the valve rod and reduce the operation torque;
3. the valve is designed to be of fireproof and anti-static structure; it can also be customized according to the requirements of the clients or the working conditions.

Need to see more product information or to request high-quality print copy please contact us
Contact us
Product Detail

Design standards
Design standsrds:GB/T 12237/ API6D/API608
Structure length:GB/T12221,API6D,ASME B16.10
Connrction flange:JB79,GB/T 9113.1,ASME B16.5,B16.47
Welding end:GB/T 1222,ASME B16.25
Test and inspection:GB/T 13927,API6D,API 598

Performance Specification
Nominal pressure:PN16,PN25,PN40,150,300LB
Strength test:PT2.4,3.8,6.0,3.0,7.5MPA
Seal test:1.8,2.8,4.4,2.2,5.5MPA
Gas seal test:0.6MPa
The valve main material:A105(C),F034(P),F316(R)
Suitable medium:the lonq-distance pipeline for,natural gas, petroleum,heating and thermal power pipe net.
Suitable temperature:-29°C~150°C

Product Structure
